The Musaicum Macaronesia

The Musaicum Macaronesia satellite image mosaic - Canary Islands and Madeira

The Musaicum Macaronesia is a regional visible color satellite image mosaic of the Azores, the Canary Islands, Madeira and Cabo Verde with a ground resolution of 10m. It combines recent Sentinel-2 satellite imagery into the highest quality and most cloud free depiction of the region in this resolution class available today.

It is generated using a classical mosaicing process derived from the methods and techniques developed for local mosaics but with a high degree of automatization. This eliminates most of the time intensive manual steps while maintaining high quality standards.

Compared to the Green Marble the Musaicum Macaronesia offers much higher spatial resolution (10m compared to 250/300m) at the cost of slightly more heterogeneous coloring due to the smaller data basis. Cloud occurrence is comparable to my hand produced local mosaics with less than about one in 100k pixels significantly affected by clouds.

Compared to the Musaicum EU-Plus and the Musaicum West Asia this mosaic is based on improved aggregation techniques with in particular better color calibration and uniformity.

Primary data source for the image is Sentinel-2 imagery from 2020 to 2024 for the Azores, 2022-2025 for Madeira, the Canary Islands and Cabo Verde.

Key properties

Visible color mosaic of the Azores, the Canary Islands, Madeira and Cabo Verde
10m base resolution
Based on Sentinel-2 data from 2020 to 2025
Includes full coverage of lakes and coastal waters, no coverage of the open ocean
Shows atmosphere compensated surface color, available either as linear surface reflectance values or tone mapped for direct display
Available with illumination as recorded and with shading compensation

Product packaging

The mosaic is produced in different projections for different parts of the coverage area and is assembled in the target projection on demand. The previews of the different parts shown here are in UTM projections. For use in web maps in Mercator projection by default a z14 grid (9.5546m nominal resolution) is provided.

The standard form of distribution of this mosaic is with an alpha channel for seamless blending with a background image for the open ocean - like the Green Marble. This is illustrated in the samples below. Other variants can be produced on request.

Product options

In addition to the mosaic with illumination as recorded - which is the recommended version for direct visual applications - this mosaic is also available in a shading compensated version where the differences in illumination due to the topography and shadows cast by mountains are compensated for. This version can be used for example in applications where a synthetic illumination is used to generate a custom shading effect.

Supplementary to the visual color mosaic a vegetation data set is available with the same coverage and source data, documenting the fractional herbaceous and woody vegetation as well as fractional water cover for every 10m pixel.

Sample gallery
